Easy­Tool MFC

PC software for configuration, parameterization and creation of applications for the multifunction controller (HE 5697 MFC)


Engineering Tool for HE 5697 MFC

Creating applications

individual design of operating pages

Configure instead of program




Request Product



Easy­Tool MFC – Soft­ware pro­gram

Mapcom­plex process flows intu­itively, quickly and com­pletely with­out pro­gram­ming knowl­edge!

This is made pos­si­ble by the engi­neer­ing tool “Easy­Tool MFC”, together with the mul­ti­func­tion con­troller HE 5697 MFC.



  • Cre­ation of user-defined oper­at­ing pages for the indi­vid­ual design and oper­a­tion of the mul­ti­func­tion con­troller
  • Cre­ation of user-defined pro­grams / appli­ca­tions based on var­i­ous basic libraries and their wiring
  • Test of the oper­at­ing struc­ture and the pro­gram in the form of a device sim­u­la­tion
  • Dia­gram-ori­ented online dis­play of process val­ues to sup­port pro­gram test­ing and com­mis­sion­ing
  • Debug­ging of the pro­gram to test the entire appli­ca­tion


Test free of charge and for an unlim­ited time

Easy­Tool MFC can be tested for an unlim­ited period of time. A USB license key (don­gle) is only required to trans­fer the cre­ated appli­ca­tion to the mul­ti­func­tion con­troller.

This can be ordered with the item no. #56979004 avail­able for pur­chase.



Easy­ToolMFC Vers. 1.5 Installer | Dejavu char­ac­ter cover


The fol­low­ing third-party soft­ware pack­ages are used in this soft­ware: - QT 4.8.6 LGPL license (http://www.gnu.org/licenses/lgpl-2.1.html) - QWT 6.1.0 LGPL license (http://www.gnu.org/licenses/lgpl-2.1.html)

Oper­at­ing Instruc­tions Easy­Tool MFC – Ger­man

Oper­at­ing Instruc­tions Easy­Tool MFC – Eng­lish
